product name

Drive Rui 3050 hook arm garbage truck

gross mass (kg)

2995

Tank volume (m3)

Rated mass (kg)

1385

outline dimension (mm)

4620X1710X1960

curb weight (kg)

1480

Goods Chamber Size (mm)

XX

Rated passenger capacity (person)

Total mass of quasi-trailer (kg)

Number of passengers (person)

2

Saddle load mass (kg)

Approach angle / departure angle of (°)

34/18

Front suspension / rear suspension (mm)

605/945

axle weight (kg)

1450/1545

speed of a motor vehicle (km/h)

100

remarks:

Note: ABS model: YF 9; ABS manufacturer: Wuhan Yuanfeng Automobile Electronic Control System Co., Ltd.; engine net power value: DAM15KR is 80kW; optional description: optional cab, only DAM15KR engine, only 3070mm wheelbase, ETC vehicle device; engine / fuel consumption value (L / 100km): DAM15KR / 7.9; special function and device: the vehicle realizes garbage loading and unloading function through hook arm and hydraulic system;

[Chassis technical parameters]

Chassis model

BJ1030V4JV5-01 Class II Beiqi Foton Motor Co., LTD

Chassis name

truck chassis

name

Fukuda card

manufacturing enterprise

Beiqi Foton Motor Co., Ltd

number of axles

2

Number of tires

4

wheel base (mm)

3070,3170

tyre size

175R14LT 8PR

Number of steel plate spring sheets

-/5

front gauge (mm)

1338

Fuel types

gasoline

rear track (mm)

1375,1455

Emission basis standard

GB18352.6-2016 Country

engine type

Engine production enterprise

engine displacement

engine power

DAM15KR

DAM16KR

Harbin Dong'an Automobile Power Co., Ltd

Harbin Dong'an Automobile Power Co., Ltd

1498

1597

85

90
