Product description |
|
|
Place of Origin |
SUIZHOU, CHINA |
|
Brand Name |
CLW |
|
Certification |
CCC, SGS, BV, DOT, GCC |
|
Model Number |
CLW5120 |
|
Payment & Shipping Terms |
|
|
Minimum Order Quantity |
1 |
|
Unit Price |
Negotiable |
|
Packaging Details |
naked,waxed,bulk ship,ro-ro |
|
Delivery Time |
30-35 days |
|
Payment Terms |
L/C, D/A, D/P, T/T, Western Union, MoneyGram |
|
Supply Ability |
500 Unit/Month |
The main technical parameters of the CLW5090ZXX6 carriage removable garbage truck | |||
product ** | Cheng Liwei | the name of firm | Cheng Li Special purpose Vehicle Co., LTD |
Vehicle model | CLW5090ZXX6 | Announcement batch | 328 |
outline dimension (mm) | 5980×2320×2390,2520 | Tank volume (m3) | |
gross mass (kg) | 9** | Rated mass (kg) | 5205,4905 |
curb weight (kg) | 3700,4000 | Front-row passenger (person) | 3 |
axle weight (kg) | 3300/5800 | exemption from conscription | yes |
* * High speed speed (km/h) | 103 | fuel oil | deny |
Fuel consumption (L / * * Km) | 6.5,17.2,17.1,17.3,17.3,17. | environmental protection | yes |
Fuel type | diesel oil | effluent standard | Six countries |
other | 1. The vehicle realizes the operation function of garbage loading and unloading through the pulling device and hydraulic system.2, the car only uses 3800mm wheelbase.3, protective material: Q235B carbon steel, connection mode: the left and right sides and the rear lower protection are used by welding connection, the rear protection section size (mm): * * 50, the rear protection height from the ground (mm): 420. 4. ABS model / Manufacturer: ABS Model: ABS / ASR-24V-4S / 4M, manufacturer: Xiangyang Dongfeng Longcheng Machinery Co., LTD.5. The corresponding relationship between engine model and fuel consumption value is (L / * * km): YCY24140-60 / 16.., ZD30D16-6N / 17.2, D25TCIF1 / 17.1, D30TCIF1 / 17.3, NV 30-C6G / 17.3, NV 30-C6D / 17.1. 6. Select the cab along with the chassis. | ||
Cheng liwei CLW5090ZXX6 compartment unloading type garbage truck chassis parameters | |||
Chassis model | EQ1095SJ8CD2 | Chassis brand | Dongfeng brand |
number of axles | 2 | front gauge (mm) | 1745 |
wheel base (mm) | 3308,3800 | rear track (mm) | 1586,1630,1650,1800 |
Number of tires: | 6 | tyre size | 7.50R16 |
Close to the corner of departure | 21/14 | Front suspension and rear suspension | 1130/1050 |
Cheng liwei CLW5090ZXX6 compartment unloading garbage truck engine parameters | |||
engine type | Engine production enterprise | displacement (ML) | power (KW) |
YCY24140-60 | Guangxi Yuchai Machinery Co., LTD | 2360 | 103/140 |
ZD30D16-6N | Dongfeng Light Engine Co., Ltd | 2953 | 120/163 |
D25TCIF1 | Kunming Yunnei Power Co., LTD | 2499 | 110/149 |
D30TCIF1 | Kunming Yunnei Power Co., LTD | 2977 | 125/170 |
NV30-C6G | Dongfeng Chaoyang Chachai Power Co., LTD | 2968 | 115/156 |
NV30-C6D | Dongfeng Chaoyang Chachai Power Co., LTD | 2968 | 120/163 |
