Product description |
|
|
Place of Origin |
SUIZHOU, CHINA |
|
Brand Name |
CLW |
|
Certification |
CCC, SGS, BV, DOT, GCC |
|
Model Number |
CLW5120 |
|
Payment & Shipping Terms |
|
|
Minimum Order Quantity |
1 |
|
Unit Price |
Negotiable |
|
Packaging Details |
naked,waxed,bulk ship,ro-ro |
|
Delivery Time |
30-35 days |
|
Payment Terms |
L/C, D/A, D/P, T/T, Western Union, MoneyGram |
|
Supply Ability |
500 Unit/Month |
The main technical parameters of the CLW5030ZXXB6 car removable garbage truck | |||
product ** | Cheng Liwei | the name of firm | Cheng Li Special purpose Vehicle Co., LTD |
Vehicle model | CLW5030ZXXB6 | Announcement batch | 324 |
outline dimension (mm) | 4575,4675×1670×1940 | Tank volume (m3) | |
gross mass (kg) | 2995 | Rated mass (kg) | 1385 |
curb weight (kg) | 1480 | Front-row passenger (person) | 2 |
axle weight (kg) | 1450/1545 | exemption from conscription | yes |
* * High speed speed (km/h) | ** | fuel oil | deny |
Fuel consumption (L / * * Km) | 7.5 | environmental protection | deny |
Fuel type | gasoline | effluent standard | Six countries |
other | 1. The vehicle realizes the operation loading and unloading function of garbage through the pulling device and hydraulic system.2. The corresponding relationship between vehicle length / wheelbase is (mm): 4575 / 3070,4675 / 3170. 3, ABS system * * mode is dual-parameter * *, ABS system * * device model is YF 9, ABS system * * device manufacturer is Wuhan Yuanfeng Automobile Electronic Control System Co., LTD.4, engine and fuel consumption value (L / * * Km): DAM15KR / 7.5. | ||
Cheng liwei CLW5030ZXXB6 compartment unloading type garbage truck chassis parameters | |||
Chassis model | BJ1030V4JV5-01 | Chassis brand | Fukuda card |
number of axles | 2 | front gauge (mm) | 1338 |
wheel base (mm) | 3070,3170 | rear track (mm) | 1375,1455 |
Number of tires: | 4 | tyre size | 175R14LT 8PR |
Close to the corner of departure | 34/26 | Front suspension and rear suspension | 605/900 |
Cheng liwei CLW5030ZXXB6 compartment unloading garbage truck engine parameters | |||
engine type | Engine production enterprise | displacement (ML) | power (KW) |
DAM15KR | Harbin Dong'an Automobile Power Co., Ltd | 1498 | 85/115 |
